Grundfos magna3 - MAGNA3 D 65-150 F Data

Performance curves and technical data
9
52
MAGNA3Performance curves and technical data
MAGNA3 D 65-150 F 1 x 230 V, 60 Hz
For product numbers, see page 62.
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
48
52
56
Q [US gpm]0 50 100 150 200 250 300
350
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
48
52
56
Q [US gpm]0 40 80 120 160 200 240 280
P1
[W]
[W]
0
200
400
600
800
1,000
1,200
1,400
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
48
52
56
Q [US gpm]0 50 100 150 200 250 300 350
P1
0
500
1,000
1,500
2,000
2,500
3,000
3,500
4,000
AUTOADAPT
Proportional pressure Constant pressure 0-10 volt*
Speed
P1 [W]
230 V
I
1
[A]
230 V
Min. 29 0.30
Max. 1409 6.18
The pump incorporates overload protection.
Net weights
[lb (kg)]
Ship. vol.
[ft
3
(m
3
)]
101 (45.8) 2.12 (0.06)
* External setpoint influence shown with a
setpoint of H
max
Connections: GF53/65 flanges.
See Pipe connections, page 61.
System pressure: Max. 175 psi (1.2 MPa) (12 bar).
Liquid temperature: 14 to 230 °F (-10 to +110 °C) (TF 110).
Specific EEI: 0.17.
TM05 2205 2214
Pump type Dimensions [in (mm)]
MAGNA3 D 65-150 F
L1 L2 L3 L4 L5 B1 B3 B4 B5
13.4 (340) 8.58 (218) 3.62 (92) 3.62 (92) 8.03 (204) 3.31 (84) 20.55 (522) 8.98 (228) 11.57 (294)
D1 D2 D3 D4 D5 D5 (2) M M1 H1
2.56 (65) 4.69 (119) 5.12/5.71 (130/145) 7.28 (185) 0.55 (14) 0.75 (19) M12 Rp 1/4 3.03 (77)
