Grundfos magna3 User Manual

Performance curves and technical data
9
56
MAGNA3Performance curves and technical data
MAGNA3 D 100-120 F 1 x 230 V, 60 Hz
For product numbers, see page 62.
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
48
Q [US gpm]0 50 100 150 200 250 300
P1
[W]
0
200
400
600
800
1,000
1,200
1,400
1,600
Q [US gpm]
H
[ft]
0
4
8
12
16
20
24
28
32
40
44
48
0 50 100 150 200 250 300 350 400 450
36
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
48
Q [US gpm]0 50 100 150 200 250 300 350 400 450
AUTOADAPT
P1
0
500
1,000
1,500
2,000
2,500
3,000
3,500
4,000
4,500
[W]
Proportional pressure Constant pressure 0-10 volts*
Speed
P1 [W]
230 V
I
1
[A]
230 V
Min. 35 0.35
Max. 1550 6.78
The pump incorporates overload protection.
Net weights
[lb (kg)]
Ship. vol.
[ft
3
(m
3
)]
138.3 (62.7) 7.4 (0.208)
* External setpoint influence shown with a
setpoint of H
max
Connections: GF100 flanges.
See Pipe connections, page 61.
System pressure: Max. 175 psi (1.2 MPa) (12 bar).
Liquid temperature: -14 to 230 °F (10 to +110 °C) (TF 110).
Specific EEI: 0.17.
TM05 7701 1214
D4 D3 D2 D1
D5
Pump type Dimensions [in (mm)]
MAGNA3 D 100-120 F
L1 L2 L3 L4 L5 B1 B3 B4 B5
17.72 (450) 9.57 (243) 5.79 (147) 5.79 (147) 8.03 (204) 3.31 (84) 21.69 (551) 9.92 (252) 11.77 (299)
D1 D2 D3 D4 D5 M M1 H1 H2
3.94 (100) 6.3 (160) 6.69 (170) 8.66 (220) 0.75 (19) M12 Rp 1/4 4.06 (103) 12.99 (330)

Grundfos magna3 Specifications

General

Liquid Temperature Range	-10°C to +110°C
Max Operating Pressure	16 bar
Type	Circulator Pump
Series	MAGNA3
Operating Temperature Range	-10°C to +110°C
Ambient Temperature Range	0°C to +40°C
Protection Class	IPX4D
Power Supply	1 x 230 V, 3 x 230 V, 3 x 400 V
Control Mode	Constant pressure, Proportional pressure
Communication	Modbus RTU
Pump Housing	Cast Iron
Impeller	Composite
Enclosure Class	X4D
Approvals	CE, EAC
Connection	Flange
Weight	Varies depending on model
Power Consumption	Varies depending on model
