Grundfos magna3 - MAGNA3 50-80 F (N) Data

Performance curves and technical data
9
48
MAGNA3Performance curves and technical data
MAGNA3 50-80 F (N) 1 x 115, 230 V, 60 Hz
For product numbers, see page 62.
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
Q [US gpm]0 20 40 60 80 100 120 140
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
Q [US gpm]0 20 40 60 80 100 120 140
P1
[W]
0
50
100
150
200
250
300
350
H
[ft]
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
Q [US gpm]0 20 40 60 80 100 120 140
P1
[W]
0
50
100
150
200
250
300
350
AUTOADAPT
Proportional pressure Constant pressure 0-10 volts*
Speed
P1 [W]
115 V
I
1
[A]
115 V
P1 [W]
230 V
I
1
[A]
230 V
Min. 18.5 0.31 18.5 0.22
Max. 341 3.09 330 1.58
The pump incorporates overload protection.
Net weights
[lb (kg)]
Ship. vol.
[ft
3
(m
3
)]
39.3 (17.8) 1.77 (0.05)
* External setpoint influence shown with a
setpoint of H
max
Connections: GF53 flanges.
See Pipe connections, page 61.
System pressure: Max. 175 psi (1.2 MPa) (12 bar).
Liquid temperature: 14 to 230 °F (-10 to +110 °C) (TF 110).
Also available with: Stainless-steel pump housing, type N.
Specific EEI:
0.19 (115V)
0.18 (230V)
TM05 7652 1413
B2
L5 L1
B7
B4
B6
H3
H1 H6
H4 H2
B1
D1 D2 D3 D4
ØD5
Pump type Dimensions [in (mm)]
MAGNA3 50-80 F (N)
L1 L5 B1 B2 B4 B6 B7 D1 D2
9.45 (240) 8.03 (204) 3.31 (84) 6.46 (164) 2.87 (73) 5 (127) 5 (127) 1.97 (50) 3.90 (99)
D3 D4 D5 H1 H2 H3 H4 H6
4.33/4.92 (110/125) 6.5 (165) 0.55/0.75 (14/19) 2.8 (71) 12.05 (306) 14.84 (377) 3.82 (97) 2.05 (52)
