Grundfos magna3 - MAGNA3 40-120 F (N) Data

Performance curves and technical data
9
46
MAGNA3Performance curves and technical data
MAGNA3 40-120 F (N) 1 x 115, 230 V, 60 Hz
For product numbers, see page 62.
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
Q [US gpm]
0
10 20 30 40 50 60 70 80 90 100 110 120
P1
[W]
0
100
200
300
400
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
Q [US gpm]0 10 20 30 40 50 60 70 80 90 100 110 120
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
H
[ft]
0
4
8
12
16
20
24
28
32
36
40
44
Q [US gpm]0 10 20 30 40 50 60 70 80 90 100 110 120
P1
[W]
0
100
200
300
400
AUTOADAPT
Proportional pressure Constant pressure 0-10 volts*
Speed
P1 [W]
115 V
I
1
[A]
115 V
P1 [W]
230 V
I
1
[A]
230 V
Min. 16 0.26 16 0.19
Max. 448 3.96 440 2.00
The pump incorporates overload protection.
Net weights
[lb (kg)]
Ship. vol.
[ft
3
(m
3
)]
35.8 (16.2) 1.42 (0.04)
* External setpoint influence shown with a
setpoint of H
max
Connections: GF15/26/40/43 flanges.
See Pipe connections, page 61.
System pressure: Max. 175 psi (1.2 MPa) (12 bar).
Liquid temperature: 14 to 230 °F (-10 to +110 °C) (TF 110).
Also available with: Stainless-steel pump housing, type N.
Specific EEI:
0.19 (115V)
0.19 (230V)
TM05 7651 1413
B2
L5 L1
B7
B4
B6
H3
H1 H6
H4 H2
B1
D4 D3 D2 D1
D5
Pump type Dimensions [in (mm)]
MAGNA3 40-120 F (N)
L1 L5 B1 B2 B4 B6 B7 D1 D2
8.5 (216) 8.03 (204) 3.31 (84) 6.46 (164) 2.87 (73) 4.37 (111) 4.37 (111) 1.57 (40) 1.93 (49)
D3 D4 D5 H1 H2 H3 H4 H6
2.4 (60) 3.15 (80) 0.5 (12.8) 1.46 (37) 11.97 (304) 13.3 (338) 2.76 (70) 1.97 (50)
