10.2 Guide for engine-driven generators in submersible pump applications
Note:
• The table is based on typical +176 °F (+80
°C) rise continuous duty generators with 35
% maximum voltage dip during startup of
single-phase and three-phase motors.
• Contact the manufacturer of the generator to
make sure the unit has adequate capacity to
run the submersible motor.
• If the generator rating is in KVA instead of
kilowatts, multiply the above ratings by 1.25
to obtain KVA.
1- or 3-phase motor
[Hp]
Generator [kW]
Externally regulated Internally regulated
0.33 1.5 1.2
0.5 2.0 1.5
0.75 3.0 2.0
14.02.5
1.5 5.0 3.0
27.5 4.0
3 10.0 5.0
5.0 15.0 7.5
7.5 20.0 10.0
10.0 30.0 15.0
15.0 40.0 20.0
20.0 60.0 25.0
25.0 75.0 30.0
30.0 100.0 40.0
40.0 100.0 50.0
50.0 150.0 60.0
60.0 175.0 75.0
75.0 250.0 100.0
100.0 300.0 150.0
125.0 375.0 175.0
150.0 450.0 200.0
200.0 600.0 275.0

Grundfos SP Specifications

General

Material	Stainless Steel
Pump Type	Submersible
Application	Irrigation
Motor Range	0.37 kW to 4 kW
Liquid Temperature	0 °C to 40 °C
Series	SP
Power Range	0.37 kW to 4 kW
Frequency	50 Hz, 60 Hz
Head	Up to 200 m
Discharge Size	1 inch to 4 inches
