Grundfos SP User Manual

42
English (US)
Grundfos submersible motors, 60 Hz
Hp Ph
Volt
[V]
SF
Circuit breaker
or fuses
Amperage Full load
Max.
thrust
[lbs]
Std. Delay
Start
[A]
Max.
[A]
Eff.
[%]
Power
factor
6-inch, three-phase motors
7.5 3 208-230 1.15 65 40 114-130 23.4 - 27.5 81 85-84 6070
7.5 3 460 1.15 30 17 68 13.2 81 85 6070
7.5 3 575 1.15 30 17 51 10.2 81 85 6070
10 3 208-230 1.15 90 50 126-142 30.0 - 37.5 82 86-84 6070
10 3 460 1.15 40 25 75 17.4 82 85 6070
10 3 575 1.15 40 25 56.5 13.4 82 85 6070
15 3 208-230 1.15 130 75 198-224 44.5 - 53.5 83 86-84 6070
15 3 460 1.15 60 35 112 25 83 84 6070
15 3 575 1.15 60 35 84 19.4 83 84 6070
20 3 208-230 1.15 175 100 310-350 57.5 - 71.5 84 86-84 6070
20 3 460 1.15 80 45 186 33.5 84 84 6070
20 3 575 1.15 80 45 144 26 84 84 6070
25 3 208-230 1.15 200 125 395-445 71-87 84 87-84 6070
25 3 460 1.15 100 60 236 41 84 84 6070
25 3 575 1.15 100 60 180 32 84 84 6070
30 3 208-230 1.15 250 150 445-500 81-104 84 87-84 6070
30 3 460 1.15 125 70 265 48 85 85 6070
30 3 575 1.15 125 70 194 37 85 85 6070
40 3 460 1.15 170 90 330 65 85 84 6070
40 3 575 1.15 170 90 250 49.5 85 84 6070
50 3 460 1.15 225 125 405 73.0 83 83 6182
8-inch, three-phase motors
40 3 460 1.15 175 100 380 55.7 83 85 13000
50 3 460 1.15 225 125 550 67.8 84 85 13000
60 3 460 1.15 250 150 640 80.4 86 85 13000
75 3 460 1.15 300 175 580 97.4 86 86 13000
100 3 460 1.15 400 225 570 130.4 87 86 13000
125 3 460 1.15 500 300 600 160.0 87 87 13000
150 3 460 1.15 600 350 580 191.3 86 87 13000
10-inch, three-phase motors
175 3 460 1.15 700 400 570 230.4 88 85 13000
200 3 460 1.15 800 500 620 265.2 87 82 13000
250 3 460 1.15 1100 600 610 352.2 87 79 13000

Grundfos SP Specifications

General

Material	Stainless Steel
Pump Type	Submersible
Application	Irrigation
Motor Range	0.37 kW to 4 kW
Liquid Temperature	0 °C to 40 °C
Series	SP
Power Range	0.37 kW to 4 kW
Frequency	50 Hz, 60 Hz
Head	Up to 200 m
Discharge Size	1 inch to 4 inches
