Grundig DTR 1560 MICRO - Overview; The Digital Receiver; The Infrared Receiver

6
The digital receiver
ÉÉ
Socket for the indoor or outdoor antenna.
IR remote Connection socket for the infrared receiver.
12 VDC, 6 W max. Connection socket for the mains adapter supplied.
EURO AV Euro AV (output) plug for the television.
The infrared receiver
The infrared receiver receives the infrared signals of the remote
control and forwards the commands by wire to the receiver. Position
the infrared receiver so that it can receive the remote control
commands.
When you switch on from standby, the receiver switches to the last
selected station (Last Station Memory).
•
(red) The digital receiver is in standby mode.
•
(green) The digital receiver is switched on.
OVERVIEW____________________________________________
