4. Installation
30 PNEG-2343 U-Trough Free Flow Unloading System
3. Install the braces (49) to the support wheels and brace mounting plates (48). (See Figure 4AE and
Figure 4AF.)
Figure 4AE
Figure 4AF
Ref # Description Ref # Description
1 1/2" x 1-1/2" Bolt (4) 48 Sweep Brace Mounting Plate
20 1/2" Flange Nut (4)
49 Sweep Brace
22 3/4" Hex Nut (4)
1
20
49
49
22
48
49
