GSi 2021 User Manual

4. Installation
PNEG-2343 U-Trough Free Flow Unloading System 31
Sweep Stop
1. Mount the sweep stop (42) such that it will stop the sweep before it reaches the walk through door.
(See Figure 4AG.)
2. Install the bolt containing a through hole (104) at height shown. Feed cable through hole (104) and
reconnect to the sweep stop (42). (See Figure 4AH and Figure 4AI.)
Figure 4AG
Figure 4AH
Figure 4AI
NOTE: Only operate sweep stop from the outside of the bin.
42
104
Ref # Description
42 Sweep Stop
104 Feed Cable Through Hole
