4. Installation
PNEG-2343 U-Trough Free Flow Unloading System 33
5. See Figure 4AN-Figure 4AS for position options.
Figure 4AN Note Slot Position (Back View)
Figure 4AO Note Slot Position (Back View)
Figure 4AP Note Slot Position (Back View)
Figure 4AQ More Aggressive (Front View)
Figure 4AR Neutral (Front View)
Figure 4AS Less Aggressive (Front View)
24
Ref # Description
24 Loosen this Nut
