Warning signs (4 enclosed) to be installed on each side
of the gate (3–5 feet above the bottom of the gate).
Product identification and manual operation instruction
label (1) installed on control box.
Logo and warning labels (2) installed on each side of master operator housing.
Logo and warning labels (2) installed on each side of second operator housing.
Maximum Gate: 650 lb. (294.8 kg); 16 ft. (4.9 m)
Voltage: 12 Vdc; Frequency: 0 Hz; Power: 60 W
Class I Vehicular Swing Gate Operator.
Serial Number: XXXXXX
9901178
Conforms to UL 325 STANDARDS
TO MANUALLY OPEN AND CLOSE THE GATE:
1. Turn control box power switch OFF.
2. Disconnect front or rear mount.
3. Pull operator away from front or rear mounts.
DC SWING SERIES
Gates That Open, LLC • Tallahassee, Florida USA
Disconnect operator ONLY when the control box power
switch is OFF and the gate is NOT moving.
L
I
S
T
E
D
US
C
XXXXXX
