GTO 3000XLS - Wiring Accessories Diagram; Automatic Gate Lock Wiring; Push Button Control Wiring; Digital Keypad Wiring

24 GTO 3000XLS/3200XLS Instruction Manual © 01.10.12
GRNCOM COM
CYCLE
CLOSE
SAFETY
SHADOW
LOOP
CLOSE
EDGE
OPEN
EDGE
EXIT
OPEN
BLK
RECEIVER
RED
ALM
ORGBLUE BRN RED
MASTER INPUTS
BLK
MASTER CABLE
CONTROL INPUTS
1
2 3
4
5
6
7
SOLAR
or
18 VAC
WHTGRN
LOCK
PWR
AUX
RLY
GTO
TRANSF
LOCK
PWR
AUX
RLY
Photo Beams
Push Button Control
Automatic Gate Lock
According to
Application
Vehicle Sensor
Refer to Vehicle Sensor
manual for additional
connections.
Edge Sensor
NOTE: Connections are for typical applications.
There may be additional connection options for
applications that are not illustrated here.
2
1
1
3
1
1
Digital Keypad
4
1
2
1
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PRS
8
TUV
9
WXY
0
7
6
Connecting Other Auxiliary Devices (Sirens, Lights, etc.)
 • These2terminalsarenormallyopen“dry-contact”(novoltage)relayouput.
 •Relayisclosedwhengateisinmotion;relayisopenwhengateisnotmoving.
 •These2terminalsmaximumratingis24Vdc,1Amp.
Wiring Accessories
RLY
AUX
