GTO 3000XLS - 3200 XLS Second Operator Parts; 3200 XLS Operator Unit; Bracket Box HB301 for 3200 XLS; Hardware Bag H301 P for 3200 XLS

GTO 3000XLS/3200XLS Instruction Manual © 01.10.12 5
6. 3200XLS Parts List
Gate Bracket (1)
Post Pivot Bracket (1)
Post Bracket (1)
Closed Position
Stop Plates (1)
Warning Signs (2)
Second Gate Operator (1)
PRO3200ARMXLS
40’ Power Cable
BRACKET BOX - HB301
HARDWARE BAG - H301P
Hairpin Clip (2)
3/8" x 2-1/2" Clevis Pin (1)
1/2" x 2-3/4" Bolt (2)
3/8" x 3" Bolt (2)
3/8" x 8" Bolt (4)
8" Nylon Cable Tie (14)
3/8" Washer (12)
3/8" Lock Washer (6)
1/2" Washer (2)
3/8" x 3/16" Bushing (2)3/8" x 1/2" Bushing (1)
3/8" Nut (6)
1/2" Lock Nut (2)
2" Screw (5)
3/8" x 1-3/4" Clevis Pin (1)
