GTO 3000XLS/3200XLS Instruction Manual © 01.10.12 1
GTO/ACCESS SYSTEMS 3000XLS/3200XLS AUTOMATIC GATE OPERATOR
DRIVE
 • Lowfrictionscrewdrive(linearactuator)ratedfor-5ºFto+160ºF(-21ºCto+71ºC).UseofGTObatteryheaterFM316
(Not solar compatible) is recommended in extreme cold temperatures.
 • Poweredbya12Vmotorwithintegralcasehardenedsteelgearreducer.Motorspeedreducedto375rpm.
 • Maximumopeningarcof110º.Approximateopeningtime(90º):15-20seconds,dependingonweightofgate.
POWER
 • Thesystemispoweredbya12Vdc,7.0Ah,sealed,rechargeableacidbattery.
 • Batterychargeismaintainedbya120Vac,18Vacoutputtransformer.Blade-stylecontrolboardfuseisratedfor25A.
NOTE: The transformer should not be directly connected to any battery. Do not replace fuses with higher ampere rated
fuses; doing so will void your warranty and may damage your control board.
 • Foroptionalsolarchargingseepage2.
CONTROL
 • GTOmicroprocessor-basedcontrolboardissetforpull-to-opengateinstallations.DIPswitchescanbeadjustedto
accommodate an optional kit for push-to-open gates (see Accessory Catalog).
 • Acircuitonthecontrolboardregulatescharging.“Sleepdraw”is25mA;“activedraw”is3to7A.
 • Auto-memorizationofdigitaltransmittercode.
 • GTOremote-mountedRFreceivertunedto318MHz.
 • Operatorlengthwithpush-pulltubefullyretractedis40
1
/
4
”, mounting point to mounting point, arm stroke 16” max.
 • Minimumgatelengthis5ft.
 • Adjustableauto-close(3to120seconds),andstallforcepotentiometers.
 • Powerterminalblockaccommodatesatransformerorsolarpanels(notboth).
 • DIPswitchessimplifysetupofgateoperator.
 • AccessoryterminalblockfullycompatiblewithGTOpushbuttoncontrols,digitalkeypads,loopsdetectors,etc.
 • Controlboardallowsconnectionofsafetyedgesensorsandphotoelectricsensors.
 • Audioentrapmentalarmsoundsifunitencountersanobstructiontwicewhileopeningorclosing.
OPERATIONAL CAPACITY
 • TheGateCapacityChartshowsapproximatecycles,perday,youcanexpectfromthe3000XLS/3200XLSAutomaticGate
Operators when powered with a transformer. Actual cycles may vary slightly depending upon the type and condition of
gate and installation.
NOTE: BALL BEARING HINGES SHOULD BE USED ON ALL GATES WEIGHING OVER 250 LB.
To determine the number of cycles the gate operator will perform using solar panels, please see the specications listed
on page 2.
* An operation cycle is one full opening and closing of the gate.
These specications are subject to change without notice.
Technical Specications
Gate Weight
Gate Length
GTO/ACCESS SYSTEMS 3000XLS/3200XLS Gate Capacity Chart
Estimated number of daily cycles, based on use with a transformer and one(1) 12 Volt battery
16 ft.
14 ft.
12 ft.
5 – 10 ft.
160
170
180
190
50 lb.
150
160
170
180
100 lb.
140
150
160
170
150 lb.
130
140
150
160
200 lb.
120
130
140
150
300 lb.
110
120
130
140
400 lb.
100
110
120
130
500 lb.
90
100
110
120
650 lb.
