4. Connect one meter test lead to Wire LC1 (red) at the In-
Line Connector (IC). Connect the other meter test lead
to Pin Location J1-8 on the J1 Connector previously
removed. Be careful not to damage the pin connectors
with the test leads. CONTINUITY should be measured.
5. Connect one meter test lead to Wire LC2 (black) at the
In-Line Connector (IC). Connect the other meter test
lead to Pin Location J1-15 on the J1 Connector previ-
ously removed. Be careful not to damage the pin con-
nectors with the test leads. CONTINUITY should be
measured.
RESULTS:
1. Repair or replace defective wiring.
2. Refer back to Flow Chart.
TEST 81 - CHECK IDLE CONTROL
TRANSFORMER PRIMARY WIRING
PROCEDURE:
1. Set the AUTO-OFF-MANUAL switch (SW1) to OFF.
2. Remove Fuse F1.
3. Visually verify that Wires 11 and 44 cross through the
Idle Control Transformer (ICT) from opposite sides.
(Refer to Wiring Diagram 0F7822 in Part 7).
RESULTS:
1. Correct the wiring of Wires 11 and 44 through the Idle
Control Transformer (ICT) per Wiring Diagram 0F7822.
2. If wiring checks good, replace the printed circuit board.
