BCR - BATTERY CHARGE RELAY
CB - CIRCUIT BREAKER, MAIN OUTPUT
IM1 - IGNITION MODULE, CYLINDER #1
HTO - HIGH OIL TEMPERATURE SWITCH
IM2 - IGNITION MODULE, CYLINDER #2
F1 - FUSE 15 AMP
FS1 - FUEL SOLENOID
44
DIAGRAM KEY
BA - BRUSH ASSEMBLY
33
CB
11
23194 N2 N1
33
0
SC
SM
SC
33
22
44
BATTERY
12V
RED
0
0
11
85
18
86
HTO
LOP
IM2
IM1
ENGINE AND
ALTERNATOR
SP1
SP2
FIELD
BA
0
SW1 - SWITCH, AUTO / OFF / MANUAL
TX - TRANSFORMER, 16 Vac 56 VA &
SW2 - SWITCH, SET EXERCISE
16 Vac 1 VA (DUAL SEC.)
SPST, N.C., ON-(OFF)
SCR - STARTER CONTACTOR RELAY
SP1, SP2 - SPARK PLUGS
DPDT, ON-OFF-ON
SC - STARTER CONTACTER
44
DPE
POWER
WINDING
22
11
33
S TATOR
CHARGE
WINDING
BATTERY
77 66
224A 225A
13
66
6
77
2
4
224
N2
N1
7766
11
22
0
7766
WINDING
POWER
I.C.T.
LC2
LC1
LC2
LC1
ICT - IDLE CONTROL TRANSFORMER
CS - IDLE CHOKE SOLENOID
11
0
FS2
LOP - LOW OIL PRESSURE SWITCH
SM - STARTER MOTOR
FS2 - FUEL SOLENOID(530cc V-TWIN ONLY)
16
NEUTRAL
CONTACTOR
OUTPUT TO
TRANSFER SWITCH
240VAC GENERATOR
12Vdc
COIL
RELAY
TRANSFER
UTILITY
INPUT
240VAC
TR
Page 91
DC CONTROL
SECTION 4.2
OPERATIONAL ANALYSIS
PART 4
Figure 5. Circuit Condition - Initial Transfer to Standby
• Standby power is now delivered to the standby closing coil (C2), via Wires E1 /E2, the normally open transfer
relay contacts, Wire 205, limit switch XB1, Wire B, and a bridge rectifier. The standby closing coil energizes and
the main current carrying contacts of the transfer switch are actuated to their STANDBY source side.
• As the main contacts move to their STANDBY source side, a mechanical interlock actuates limit switch XB1 to
its open position and limit switch XA1 to its “Utility” side position. When XB1 opens, standby closing coil C2 3
de-energizes.
• Standby power is delivered to the LOAD terminals (T1/T2) of the transfer switch.
• As load is applied to the generator, the current transformer (ICT) induces AC voltage that is applied to the circuit
board via Wires LC1 & LC2. This voltage is utilized for stepper motor control.
To Next Page
