Connecting your equipment to the TV (Cont.)
Connecting a satellite/cable TV set top box
Connecting to the Composite terminal
In order to watch cable/pay TV, you must subscribe to your local pay TV
provider and install its separate receiver (set top box). Connection to the
terminals of other equipment may differ depending on brand and model.
Connect a composite cable from the LED LCD TV’s Composite In terminal
to the Composite Out terminal of the cable/pay TV receiver (set top box),
making sure to match the colours of the terminals with the colours of the
plugs.
Connecting to the HDMI terminal
Connect an HDMI cable from the HDMI terminal of the set top box to the
HDMI terminal of the LED LCD TV.
Watching cable/pay TV
1. Turn on the LED LCD TV.
2. Press the SOURCE button on the remote control of the LED LCD TV and
use the up/down navigation keys [
] to select AV; then press
OK or, if the HDMI cable has been connected, select HDMI and then press
OK.
3. Turn your cable broadcasting receiver (set top box) on and select the
channel you wish to view.
Cable broadcasting receiver
Composite cable
Cable broadcasting receiver
HDMI cable
