H3C S5500-EI Series Installation Manual

1-17
SFP Port Status LED
The port mode LED and the SFP port status LED together indicate the SFP port operation status. Refer
to
Table 1-14 for details.
Table 1-14 SFP port status LEDs description
Status
Port mode
LED
Ethernet port
status LED
Description
Steady green
The port operates at a rate of 1000 Mbps; the LED is fast
flashing when data is being sent and/or received on the port.
Steady yellow
The port operates at a rate of 100 Mbps; the LED is fast
flashing when data is being sent and/or received on the port.
Flashing yellow
(3 Hz)
POST failed on the port.
Steady green
(rate mode) or
flashing green
(1 Hz, PoE
mode)
Off The port is not up.
Steady green
The port operates in full-duplex mode; the LED is fast flashing
when data is being sent and/or received on the port.
Flashing yellow
(3 Hz)
POST failed on the port.
Steady yellow
(duplex mode)
Off The port is not up.
Interface Module Status LED
Table 1-15 Interface module status LED description
Mark Status Description
Green The interface module is in the slot and operates normally.
Flashing yellow
The inserted interface module type is incorrect or the interface
module fails.
MOD1
MOD2
Off No interface module is installed.
Optional Interface Modules
The S5500-EI series provide two interface module slots on the rear panel. You can select the interface
modules in
Table 1-16 as needed.
The S5500-E1 series support IRF, requiring physical connections between devices. The 10 GE ports of
the supported interface modules support IRF, allowing you to connect the switches through these 10 GE
ports for IRF implementation.
