H3C S5500-EI Series Installation Manual

1-10
Ports
Console Port
Each S5500-EI series provides one console port on the front panel. Table 1-2 describes the console
port specifications.
Table 1-2 Console port specifications
Item Specification
Connector type RJ-45
Compliant standard EIA/TIA-232
Transmission baud
rate
9600 bps to 115200 bps (defaulting to 9600 bps)
Service
z It can be connected to an ASCII terminal.
z It can be connected to a serial port of a local or remote (through a pair of
modems) PC running terminal emulation program.
10/100/1000Base-T Ethernet Port
Each S5500-EI series provides 10/100/1000Base-T Ethernet ports on its front panel. Table 1-3
describes the specifications of the 10/100/1000Base-T Ethernet ports.
Table 1-3 10/100/1000Base-T Ethernet port specifications
Item Specification
Connector type RJ-45
Interface standard
z 10 Mbps, full duplex
z 100 Mbps, full duplex
z 1000 Mbps, full duplex
z MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.08 ft.)
Transmission medium Category-5 unshielded twisted pair cable
Standard IEEE 802.3i, 802.3u, 802.3ab
SFP Port
Each S5500-EI series provides SFP ports on its front panel. You can select the SFP transceivers
described in
Table 1-4.
All SFP transceivers are hot swappable and optional. Therefore, networking is more flexible.
