H3C S5560S-SI Series User Manual

25
4. Grasp the handle of the power supply with one hand and pull the module part way out. Support
the module bottom with the other hand, and pull the power supply slowly out of the slot along
the guide rails.
5. Place the removed power supply on an antistatic mat or put it into its original packaging bag.
6. If you are not to install a new power supply, install a filler panel in the slot.
Connecting the power cord
WARNING
!
•
Provide a circuit breaker for each power cord.
• Before connecting the power cord, make sure the circuit breaker for the power cord is turned off.
The S5560S-28F-SI, S5560S-28DP-SI, S5500V3-28S-DP-SI, S5500V3-54S-DP-SI,
S5500V3-36F-DP-SI, S5500V3-54F-DP-SI, and S5130S-28F-SI switches use removable power
supplies.
•
The S5560S-28F-SI, S5560S-28DP-SI, and S5130S-28F-SI switches support the PSR75-12A
power supply.
•
The S5500V3-28S-DP-SI, S5500V3-54S-DP-SI, S5500V3-36F-DP-SI, and
S5500V3-54F-DP-SI switches each come with a CA-70A12 power supply and supports the
CA-70A12, PSR75-12A, and PSR150-D1 power supplies.
The CA-70A12 and PSR75-12A power supplies support AC and 240 HVDC power input. However,
when installed on an S5500V3-28S-DP-SI, S5500V3-54S-DP-SI, S5500V3-36F-DP-SI, or
S5500V3-54F-DP-SI switch, they do not support 240 HVDC power input. The PSR-150-D1 power
supply supports power input from a –48VDC power source or an external redundant power system
(RPS).
Table 10 Power cord connection procedures at a glance
Switch model Available power source
Connection procedure
reference
S5130S-28S-HPWR-LI
S5130S-52S-PWR-LI
S5120V2-28P-HPWR-LI
S5120V2-52P-PWR-LI
S5048PV3-EI-PWR
S5024PV3-EI-HPWR
S3100V3-28TP-PWR-SI with
product code
LS-3100V3-28TP-PWR-SI
AC power source
Connecting the AC power cord for
the fixed AC power supply
RPS (RPS1600-A)
Connecting the DC power cord for
the fixed DC power supply
S5560S-28F-SI
S5560S-28DP-SI
S5130S-28F-SI
• AC power source
• 240 VDC high-voltage power
source
Connecting the power cord for a
CA-70A12 or PSR75-12A power
supply
S5500V3-28S-DP-SI
S5500V3-54S-DP-SI
S5500V3-36F-DP-SI
S5500V3-54F-DP-SI
• AC power source
Connecting the power cord for a
CA-70A12 or PSR75-12A power
supply
• –48 VDC power source
• RPS (available models:
RPS800-A and RPS1600-A)
Connecting the DC power cord for a
PSR150-D1 power supply
Other switch models AC power source
Connecting the AC power cord for
the fixed AC power supply
