13-12
VLAN operation
mode
With or without VLAN
tag
Packet processing
Without VLAN tag
The packet is tagged with the VLAN tag corresponding to the
default PVID of the port, and then:
z If the packet matches the configured traffic classification
rule, the packet is priority-remarked with the value specified
in the rule and is then forwarded;
z Otherwise, the packet is remarked with the port priority and
is then forwarded.
Follow these steps to configure uplink traffic classification and priority remarking for a UNI:
To do... Use the command... Remarks
Enter system view
system-view
—
Enter ONU port view
interface
interface-type interface-number
—
Configure uplink traffic
priority remarking for a
UNI
uni
uni-number
classification-marking index
index
queue
qid
priority
priority { selector operator matched-value }
&<1-4>
Required
Currently, up to eight rules can be configured for each UNI port on an H3C ONU.
