11
5. On the screen as shown in Figure 11, configure the parameters, press Enter, and then select
Submit Changes. For more information about the parameter description, see Table 2.
Figure 11 Configuring RAID array parameters
Table 2 Parameter description
Logical Drive Label RAID array name.
Stripe Size Data block size for each drive.
Size Capacity for the logical drive.
Unit Size Size for the unit.
Acceleration Method Logical drive acceleration method.
6. On the screen as shown in Figure 12, select Back to Main Menu.
