129
Figure 187 Create Logical Drive screen
Configuring RAID arrays in legacy mode
This section describes how to configure RAID arrays through a storage controller in legacy mode.
For more information about how to enter the BIOS and set the boot mode to legacy, see the BIOS
user guide for the server.
RAID array configuration tasks at a glance
To configure RAID arrays in legacy mode, perform the following tasks:
Accessing the storage controller configuration screen
Switching the operating mode
Configuring RAID 0
Configuring RAID 1
Configuring RAID 1 ADM
Configuring RAID 5
Configuring RAID 6
Configuring RAID 10
Configuring RAID 10 ADM
Configuring RAID 50
Configuring RAID 60
(Optional.) Configuring hot spare drives
(Optional.) Configuring the primary boot drive
(Optional.) Deleting a RAID array
(Optional.) Viewing drive information
