134
Figure 196 Configuring RAID 0 parameters
Table 6 Parameter description
RAID Level
The RAID level determines the drive performance, fault tolerance
capability, and logical drive capacity.
Logical Drive Name RAID array name.
Strip/Full Stripe Size Data block size for each drive.
Parity Group Count Number of RAID 1 or RAID 5 groups used to create RAID 10 or RAID 50.
Build Method Method used to create the RAID array.
Size Capacity for the RAID array.
Acceleration Method Logical drive acceleration method.
5. On the screen as shown in Figure 197, select Manage Arrays and press Enter.
