22
Figure 24 RC-2FHFL-1U-SW-G6
PCIe5.0 x16 (16,8,4,2,1) description:
• PCIe5.0: Fifth-generation signal speed.
• x16: Connector bandwidth.
• (16,8,4,2,1): Compatible bus bandwidth, including x16, x8, x4, x2, and x1.
LCD smart management module
An LCD smart management module displays basic server information, operating status, and fault
information, and provides diagnostics and troubleshooting capabilities. You can locate and
troubleshoot component failures by using the LCD module in conjunction with the event logs
generated in HDM.
