34
Product specifications
Technical specifications
Processors
• 2 × Intel
®
Xeon
®
scalable processors of the fourth generation, up to 60 cores, up
to 350 W power consumption per processor
• Supports Montage Jintide processors
• HBM technology
Chip set Intel
®
C741
Memory
• A maximum of 32 DDR5 DIMM slots and the maximum speed of 4800 MT/s
• Supports RDIMMs
• A maximum of 8 TB capacity for two processors
Storage
controllers
• Standard embedded RAID controller (supporting SATA RAID 0, 1, 5, 10)
• HBA and intelligent storage controllers based on dedicated or standard PCIe slots
FBWC cache Up to 8 GB cache, supporting the supercapacitor
Integrated
graphics
The graphics chip (model AST2600) is integrated in the BMC management chip to
provide a maximum resolution of 1920 × 1200@60Hz (32bpp)
Storage
• Up to 12 × 2.5-inch drives (10 drives at the server front and 2 at the server rear)
• Up to 4 × 3.5-inch drives (all at the server front)
• Supports SAS/SATA HDDs and SSDs, up to 12 NVMe U.2 drives, and up to 32
E1.S slots
• (Optional.) SATA/NVMe M.2 SSDs and serial & DSD module
Network
• 1 × embedded 1 Gbps dedicated management port
• Up to two embedded OCP 3.0 network adapter connectors to expand 4 × 1 GE
copper ports, 2 × 10 GE copper or fiber ports, 2 × 25 GE fiber ports, or 2 × 100 GE
fiber ports
• (Optional) Network adapter PCIe slots that support 1/10/25/100 GE network
adapters, InfiniBand cards, and intelligent network adapters
Expansion slots
• 4 × PCIe 4.0 slots (three PCIe 5.0 slots and one PCIe 4.0 slot)
• 2 × OCP 3.0 network adapter slots
• CXL1.1
Interfaces
• 2 × VGA connectors, one at the server front (not available for the E1.S model) and
one at the server rear
• 4 × USB connectors (one on the system board, two at the server rear, and one at
the server front)
• 1 × Type-C dedicated management interface (at the server front)
• 1 × serial port (optional)
GPU support Up to four single-width GPUs
Management
software
• HDM (agentless tool, with dedicated management interface) & H3C FIST
• Supports LCD smart management module, with a local video memory of 64 MB.
• (Optional.) Supports U-Center data center management platform
Security
Supports chassis intrusion detection, TCM/TPM module, two-factor authentication, and
Intel PFR 3.0 and SGX 2.0
Power supplies
• (Optional.) Platinum 550W/800W/850W/1200W/1300W/1600W/2000W power
supplies, supporting 1 + 1 redundancy
• (Optional.) -48VDC/240VDC/336VDC power supplies, supporting 1 + 1
