5
Server specifications
Components
Figure 1 Server components
(1) Chassis access panel N/A
(2) Memory
Stores computing data and data exchanged with external storage
temporarily.
(3) System battery Supplies power to the system clock to ensure system time correctness.
(4) Chassis open-alarm module
Detects if the access panel is removed. The detection result can be
displayed from the HDM Web interface.
(5) System board
One of the most important parts of a server, on which multiple
components are installed, such as processor, memory, and fan. It is
integrated with basic server components, including the BIOS chip and
PCIe connectors.
(6) Encryption module Provides encryption services for the server to enhance data security.
(7) Supercapacitor holder Secures a supercapacitor in the chassis.
(8) Supercapacitor
Supplies power to the flash card on the powerfail safeguard module,
which enables the storage controller to back up data to the flash card for
protection when power outage occurs.
(9)
module
Provides M.2 SSD slots.
Provides data storage space for the server.
