30
Figure 31 Serial & DSD module
Table 15 Component description
1 SD card slot 1
2 SD card slot 2
3 Serial port
PCIe modules
Typically, the PCIe modules are available in the following standard form factors:
• LP—Low profile.
• FHHL—Full height and half length.
• FHFL—Full height and full length.
• HHHL—Half height and half length.
• HHFL—Half height and full length.
For more information about PCIe module compatibility with riser cards, see "Riser cards."
Storage controllers
The server supports the following types of storage controllers:
• Embedded VROC controller—Embedded in the server and does not require installation.
• Standard storage controller—Comes in a standard PCIe form factor and typically requires a
riser card for installation.
