H3C UniServer R4700 G6 User Manual

6
Item
Description
(11) Riser card Provides PCIe slots.
(12) NVMe VROC module
Works with Intel VMD to provide RAID capability for the server to
virtualize storage resources of NVMe drives.
(13) Power supply
Supplies power to the server. The power supplies support hot swapping
and 1+1 redundancy.
(14) Rear drive backplane Provides power and data channels for drives at the server rear.
(15) Storage controller
Provides RAID capability to SAS/SATA drives, including RAID
configuration and RAID scale-
up. It supports online upgrade of the
controller firmware and remote configuration.
(16) Standard PCIe network
adapter
Installed in a standard PCIe slot to provide network ports.
(17) Riser card blank Installed on an empty PCIe riser connector to ensure good ventilation.
(18) OCP adapter
Provides one slot for installing an OCP network adapter and two slots for
installing drives at the server rear.
(19) Chassis N/A
(20) GPU module Provides computing services such as graphics processing and AI.
(21) Chassis ears
Attach the server to the rack. The right ear is integrated with the front I/O
component, and the left ear is integrated with VGA connector, dedicated
management connector, and USB 3.0 connector.
(22) Drive Provides data storage space. Drives support hot swapping.
(23) LCD smart management
module
Displays basic server
information, operating status, and fault
information. Together with HDM event logs, users can fast locate faulty
components and troubleshoot the server, ensuring server operation.
(24) Drive backplane Provides power and data channels for drives.
(25) Air baffle
Provides ventilation aisles for processor heatsinks and memory modules
and provides support for the supercapacitor.
(26) Processor socket cover Installed over an empty processor socket to protect pins in the socket.
(27) Processor heatsink Cools the processor.
(28) Processor
Integrates memory and PCIe controllers to provide data processing
capabilities for the server.
(29) Processor retaining bracket Attaches a processor to the heatsink.
(30) Fan
Helps server ventilation. Fans support hot swapping and N+1
redundancy.
(31) Serial & DSD module Provides two SD card slots and forms RAID 1 by default.
(32) Server management
module
Provides I/O connectors and HDM out-of-band management features.
