Figure 5 Display
1 Numeric display: Measured value
or menu options
4 Menu icon: The instrument is in
menu mode.
2 Range icon: Selected range or
parameter
5 Calibration adjusted icon: A user-
entered calibration curve was
entered.
3 Range value: Range(s) or
parameters
6 Low battery icon: Battery level is
10%. Flashes when the battery
level is too low to complete
measurements.
Operation
Configure the instrument
1. Push .
2. Push to scroll through the menu options. Push to select an
option.
Option Description
SEL Sets the measurement range or parameter. Push to toggle
between the measurement ranges or parameters.
00:00 Sets the time in 24-hour format (hh:mm). Push to change the
time. Push to change the first digit, then to go to the next
digit.
English 11
