Chapter 2, Equipment Description 35
Haemonetics
®
Cell Saver
®
Elite
®
User Manual P/N 120745-IE, Manual revision: AA
As a safety feature, the barcode reader emits a low-level laser until it detects a
barcode. It then turns on a full-power laser to scan the barcode. The reader
recognizes Codabar, Code 128, and ISBT 128 formats as valid barcode
formats.
Stop Key Pressing the (Stop) key immediately stops the pump and centrifuge. The
status indicator shows that the device is stopped. To restart the current phase,
ensure the device cover is closed; then touch (Play). To start a different
phase, touch the corresponding phase pad.
When the device is stopped in the Prime or Fill phase, double-pressing the
Stop key puts the device into Standby mode.
Touch Screen
Mount
The touch screen mount allows the user to move the touch screen horizontally
around the IV pole and adjust the angle of the screen.
USB
Connection
The USB connection is used for software upgrades and allows users to
download procedure and technical data to a portable USB flash drive.
Graphical User
Interface
The graphical user interface (GUI) provides a simple and intuitive interface for
users to use during device operation and allows easy access to advanced
configuration options.
The Processing screen is the main procedure screen and is composed
primarily of touch pads that enable you to control the procedure. If a pad is
grayed out it means that particular function is not currently available.
