EFL 3 / EFL 3C furniture lock
Power supply unit PS 4
MLA8
Feature Value
Power supply 12 V DC
Continuous current consumption ≤ 10 mA
Current consumption max. 130 mA/40ms
Operating temperature 0 - 50 °C
Relative humidity 10 to 95%, not condensed
Degree of protection IP20
Tensile load 1,000 N
Feature Value
Power supply 100 - 240 V AC, 50-60 Hz
Output voltage 12 V DC, regulated
Output current 2500 mA
Operating temperature 0 - 45 °C
Relative humidity 10 to 95%, not condensed
Mains lead length 2,100 mm
Output cable length 1,350 mm
Approvals MM, CE, FCC, UL, Level VI, FWGB, Approved Medical Device
Feature Value
Power supply V
in
12 V DC
Current consumption max.
(incl. 8x EFL 3)
1240 mA
Operating temperature 0 - 50 °C
Relative humidity 10 to 95%, not condensed
Contact NC 24 V DC, 1 A max.
Connections
Connection lead (0.5 m) with plug AMP Mate-N-Lock, male
Socket voltage output AMP Mate-N-Lock, female
Socket EFL 3 / EFL 3C RJ 10
Socket EFL X AMP Mate-N-Lock, female
Socket Data in RJ 11
Socket Data out RJ 11
