51
HDE 04.10.2021 732.22.024
MLA 6P
CC 200 Powerbank
3.3 Functions
Up to four
EFL 3 / EFL 3C furniture locks can be keyed alike and / or keyed to differ in parallel with the
FT 200 / FT 200 CAP furniture terminal.
With additional MLA 6P / MLA 8 multi-lock adapters, more furniture locks can be implemented
9. Extensions and connections, page 70.
In the event of a power failure, the locks retain the locking status which was present when the
power failed.
Keyed alike operation (= factory setting)
An authorised user key simultaneously opens all locks connected to furniture terminal
FT 200 / FT 200 CAP and, if applicable, multi-lock adapters MLA 6P / MLA 8.
Feature Value
Power supply V
in
12 V DC
Current consumption max.
(incl. 6x EFL 3)
830 mA
Operating temperature 0 - 50 °C
Relative humidity 10 to 95%, not condensed
Contact NC 24 V DC, 1 A max.
Connections
Connection lead (0.5 m) with plug AMP Mate-N-Lock, male
Socket voltage output AMP Mate-N-Lock, female
Socket EFL 3 / EFL 3C RJ 10
Socket Data in (DFT) Molex 87833-042
Feature Value
Power supply 12 V DC
Operating temperature 0 - 55 °C
Relative humidity 10 to 95%, not condensed
Connections
(1x) plug for PS 4 AMP Micro, male
(2x) socket for FT 200 / MLA x AMP Mate-N-Lock, female
(1x) jack plug for Powerbank J210
Powerbank connection cable L= 3000 mm
FT 200 / MLA x / PS 4 connection
cable
L= 200 mm
