HDE 04.10.2021 732.22.024
54
4.1 Installation references
Component Installation reference
Entire system • When installing the FT 200 / FT 200 CAP furniture terminal,
please ensure that there is an inspection opening available
for emergency cases such as emergency opening of the
EFL 3 / EFL 3C or for exchanging the FT 200 / FT 200 CAP.
• Fix electrical cables in place once they have been laid in the
furniture (e.g. with cable ties).
• Electrical cables must not be under tension.
• Do not bend electrical cables.
EFL 3 / EFL 3C • Recommendation: carry out a trial mounting before installing the
EFL 3 / EFL 3C.
• Only install the locking component of the EFL 3 / EFL 3C at the
installation location.
• Only adjust the lock of the EFL 3 / EFL 3C at the installation
location and readjust if necessary after loading the furniture item.
• Ensure that there are no metal panels mounted between the
locking component and lock of the EFL 3 / EFL 3C.
• The locking component of the EFL 3 / EFL 3C can be screwed on
with a furniture handle (hole spacing 32 mm) at the opposite side.
• The EFL 3 / EFL 3C is suitable for furniture constructions with soft
closing and self-closing mechanism.
• The EFL 3 / EFL 3C is not suitable for drawers and hinged doors
with Push-to-Open function.
FAN 200 antenna • Ensure that the FAN 200 antenna is not located next to power
lines. The magnetic field of the power lines can impair the
antenna range.
• Ensure that the FAN 200 antenna is not mounted behind or on
metal surfaces or behind mirrors.
CC 200 Powerbank • In order to be able to connect a Powerbank in the event of a
power failure, lead the connector for the Powerbank out of the
furniture (e.g. via a maintenance flap or similar).
• With the CC 200 Powerbank cable connected, a maximum of one
additional FT 200 or one MLA 6P or one MLA 8
(incl. EFL 3) can be connected if an approved Powerbank is used.
