38/64 CMp | Installation
Bosch Rexroth AB, RE 15409 Version 08.2022,
7.2.3 MountingwithbracketsinsidePEC(1XX&2XX),type02
Screw M10X30 25X25
Hexagon screw M8
ISO 4017 x 20
Hexagon screw M8
ISO 4014 x 50
Washer M 10
Washer M8
Hexagon nut M8
Hexagon nut M10
Fig. 36: General picture of mounting with brackets inside PEC (1XX & 2XX)
Fig. 37: List of screws, nuts and washers
X 4
X 4
X 4X 4
X 2
X 2
X 2
DD00078004
DD00078006
