40/64 CMp | Installation
Bosch Rexroth AB, RE 15409 Version 08.2022,
7.2.4 MountingwithbracketsinsidePEC(3XX-6XX&8XX-10XX),type03
Fig. 38: General picture of mounting with brackets inside PEC (3XX-6XX & 8XX-10XX)
Washer M10
Waher M8
Hexagon nut M10
Hexagon nut M8
25X25 screw M10X30
Hexagon screw M8
ISO 4017
X 6
X 6
X 4
X 4
X 6
X 4
Fig. 39: List of screws, nuts and washers
DD00078034
DD00078035
