RE 15409, Version 08.2022, Bosch Rexroth AB
Commissioning | CMp 59/64
After the file is loaded, press the Start button, see Fig. 67: Start up load
Fig. 67: Start up load
The software is now waiting for a reset of the control unit. Reset by pressing the re-
set button on the main card, see fig 7.
Reset button
Main card
RESET
SW2
Fig. 68: Main card reset button
DD00078720
DD00078721
