35
Operation
Checking the dirt hopper
The dirt hopper is provided with an
opening in order to throw in waste col-
lected manually. The fill volume of the
dirt hopper can be monitored through
the opening (Fig. 18/1).
Fig.18
Filter system lock
The filter system is above the dirt hop-
per. The cover of the filter system is se-
cured by the lock (Fig. 19/1). The filter
and agitation device is under the cover.
Refer to Chapter "Maintenance and
Service" for information on cleaning the
filter.
Fig.19
