Hamer 525WT - FILM AND BAG SPECIFICATIONS

Rev.7 3
FILM AND BAG SPECIFICATIONS
FLAT
BAG WIDTH
9" - 16"
FLAT
BAG LENGTH
16" - 35"
1" MIN. BETWEEN PRINT
*
5" MIN.
EYE MARK
DETAIL
Ø 14-1/2" MAXIMUM
Bag Width: Minimum: 9”
Maximum: 16”
Bag Length: Minimum: 16”
Maximum: 35”
Poly Thickness: Minimum: 1.50 mil. Center Fold Film
Maximum: 4 mil. Center Fold Film
Film Roll: Maximum: 14-1/2” Diameter
NOTES:
1. EYE MARK WILL BE 1/2" IN FROM SEAL - TOWARDS THE ROLL - REGARDLESS OF WHICH WAY THE ROLL IS WOUND.
2. EYE MARK TO BE DARK COLOR (BLACK PREFERRED).
3. TO INSURE THAT YOU HAVE THE PROPER LEVEL OF CONTRAST BETWEEN THE BACKGROUND AND THE EYE MARK,
A TEST MUST BE CONDUCTED. IF YOU HAVE ANY DOUBT ABOUT HAVING ENOUGH CONTRAST, SEND SAMPLES TO HAMER LLC.
4. TINTED FILM MUST HAVE CONSISTENT TINT LEVEL - VARIATION CAUSES MISFIRE.
5. THE FILM MUST BE ABLE TO UNWIND FROM THE ROLL WITH A FORCE OF NO MORE THAN 8 POUNDS.
6. NO PRINT ALLOWED WITHIN SPECIFIED DIMENSIONS.
7. SEE BAG SPECS FOR THE BAG LENGTH / WIDTH DIMENSIONS.
8. SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE .
*
