Hamer 525WT - Page 47

ITEM QTY
PART NUMBER
DESCRIPTION
17
1
11508 SHAFT COLLAR, 5/8"
16
1
10125 SLIDE ROD
15
2
9877 STATIC ELIMINATOR BRUSH, 310
14
2
9834-1 FILM FEED ROLLER
13
1
3592 CANE
12
1
3417-2 BRACKET, STATIC ELIMINATOR
11
1
3215 BLOCK,CANE MOUNT
10
4
3125B BOLT,ROLLER
9
2
2781 WASHER, #10, SS
8
4
2595 SHCS #10-24x.5 SS
7
1
2585 WASHER,LOCK, 5/16,SS
6
4
2583 WASHER, LOCK, #10,SS
5
1
2578 WASHER,5/16
4
2
2550 HHCS 5/16-18x1 SS
3
1
2547 HHCS 5/16-18x.62,SS
2
4
2532 NUT, 3/8-16
1
2
2528 10-24 UNC HEX NUT
1
17
2
8
2
15
2
6
2
2
1
11
2
4
1
13
2
2
2
10
2
10
2
14
2
8
1
3
1
7
1
5
1
12
2
9
2
6
2
1
16
1
525 FFS FRAME
9974
REV
DWG NO.
DWG. NO.
TJB
MINNEAPOLIS, MINNESOTA
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP CORNERS
SURFACE FINISH TO BE 125 MICROINCHES
SIZE
UNLESS OTHERWISE SPECIFIED
B
REMOVE ALL BURRS
UNLESS OTHERWISE SPECIFIED
9974
SCALE
TITLE:
DRAWN BY:
DANCER/ANTI-STATIC ASSY, 525WT
Hamer LLC
DATE:
1:7
2/22/2005
AND TOLERANCES ARE
FRACTIONS 1/32
DECIMALS 2 PL .02
DECIMALS 3 PL .005
ANGLES 1/2
SHEET 2 OF 3
