Hamer 525WT - Page 49

9974
REV
DWG NO.
DWG. NO.
TJB
MINNEAPOLIS, MINNESOTA
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP CORNERS
SURFACE FINISH TO BE 125 MICROINCHES
SIZE
UNLESS OTHERWISE SPECIFIED
B
REMOVE ALL BURRS
UNLESS OTHERWISE SPECIFIED
9974
SCALE
TITLE:
DRAWN BY:
DANCER/ANTI-STATIC ASSY, 525WT
Hamer LLC
DATE:
1:6
2/22/2005
AND TOLERANCES ARE
FRACTIONS 1/32
DECIMALS 2 PL .02
DECIMALS 3 PL .005
ANGLES 1/2
SHEET 3 OF 3
1
12
1
10
1
20
1
21
1
3
1
3
1
13
1
17
1
13
1
3
1
3
1
17
1
18
2
9
3
1
1
22
2
11
1
5
1
6
1
15
1
19
1
14
1
16
1
2
1
8
2
7
4
2
525 FFS FRAME
ITEM QTY
PART NUMBER
DESCRIPTION
22
1
9957 AIR VALVE, BRAKE
21
1
9834-1 FILM FEED ROLLER
20
1
9793 DANCER WELDMENT
19
1
3250 SPRING
18
1
3222-1 BRACKET, BRAKE VALVE
17
2
3220 BUSHING, DANCER
16
1
3219 SPRING CLIP
15
1
3218 BRACKET
14
1
3145 SPRING
13
2
3125A BOLT,ROLLER
12
1
3109 SWITCH CAM ASSEMBLY
11
2
2869 HSHCS #6-32 X 1"
10
1
2830 COTTER PIN
9
2
2595 SHCS #10-24x.5 SS
8
1
2585 WASHER,LOCK, 5/16,SS
7
2
2584 WASHER, LOCK, 1/4,SS
6
1
2579 Washer,flat,3/8,SS
5
1
2548 HHCS,5/16-18x.75,SS
4
2
2542 HHCS 1/4-20x1/2 SS
3
4
2532 NUT, 3/8-16
2
1
2531 NUT,5/16-18
1
3
0634 1/8 PIPE x1/4" PLASTIC STRAIGHT CONN
