Hamer 525WT - Page 51

1. REMOVE ALL BURRS AND SHARP EDGES
2. ALL DIMENSIONS APPLY AFTER FINAL
SURFACE TREATMENT.
REVISIONS
REV. DESCRIPTION DATE
1 SEE ECO #0753 9/28/04
ITEM
QTY.
PART NUMBER
DESCRIPTION
22 1 0634 1/8 Pipe x1/4" PLASTIC STRAIGHT CONN
21
1 0635 FITTING, ELBOW, 1/8NPT - 1/4 LINE
20 3 2548 HHCS,5/16-18x3/4
19
2 2549 HHCS, 5/16-18 X 7/8
18 2 2577 WASHER, 1/4
17 4 2584 WASHER, LOCK, 1/4
16 5 2585 WASHER,LOCK, 5/16
15 2 2614 SFHCS, 1/4-20 X 1/2
14
4
2718 HHCS, 1/4-20 x 5/8
13 1 2775 NUT, JAM, 3/8-24
12
2 2786 NUT,JAM,1/4-20
11 2 2804 HHCS, 1/4-20 x 7/8
10
1 3128 PERFORATOR HOLDER ASSEMBLY
9 1 3129-1 PERFORATOR SUPPORT ASSEMBLY
8 1 3130 PERFORATOR CYLINDER BRACKET
7 1 3131 PERFORATOR GUIDE
6 1 3132 KNIFE, PERFORATOR
5
1 3133 PERFORATOR BACKUP BAR
4 1 3134 RUBBER HOLDER ASSEMBLY
3
1 3242 AIR CYLINDER
2 1 4149 PERFORATOR GUIDE H.S.
1 1 10127 EYE SUPPORT EXTENSION
NOTES - UNLESS OTHERWISE SPECIFIED DWG. NO.
9976
01
DFD
1:2.5
9976B
PERFORATOR ASSEMBLY (525) WT
10/17/00 SHEET 1 OF 1SURFACE FINISH TO BE 125 MICROINCHES
REMOVE ALL BURRS
BREAK ALL SHARP CORNERS
UNLESS OTHERWISE SPECIFIED
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
AND TOLERANCES ARE
FRACTIONS 1/32
DECIMALS 2 PL .02
DECIMALS 3 PL .005
ANGLES 1/2
DATE:
HEAT TREAT:
FINISH:
MATERIAL:
DRAWN BY:
MINNEAPOLIS, MINNESOTA
Hamer LLC
TITLE:
SCALE
SIZE
DWG NO.
REV
2
18
17
14
19
20
19
20
20
16
9
4
10
21
8
11
12
15
7
(2)
(2)
(2)
(2)
(2)
(2)
(5)
13
5
6
3
1
17
14
(2)
(2)
E
SERIAL NUMBERS:
0052596 THRU CURRENT
22
3/16" TO 7/32"
10
KNIFE LOCATION
ITEM #6 FLUSH
WITH ITEM #10
(THIS SIDE UP WHEN
MOUNTING)5
6
