1
2
1. REMOVE ALL BURRS AND SHARP EDGES
2. ALL DIMENSIONS APPLY AFTER FINAL
SURFACE TREATMENT.
3. STAMP PART WITH NUMBER IN POSITION
SHOWN.
REVISIONS
REV. DESCRIPTION DATE
2 SEE ECO #1289 8/3/2006
ITEM QTY.
PART NUMBER
DESCRIPTION
2 1 14551 PHOTO EYE CABLE
1 1 14550 PHOTO EYE DETECTOR
NOTES - UNLESS OTHERWISE SPECIFIED
3301A
DFD
DWG. NO.
SURFACE FINISH TO BE 125 MICROINCHES
BREAK ALL SHARP CORNERS
DIMENSIONS ARE IN INCHES
1
8/3/2006
REVDWG NO.SIZE SCALE
TITLE:
PHOTO EYE DETECTOR W/CABLE
Hamer LLC
MINNEAPOLIS, MINNESOTA
A 3301A
1:2
DRAWN BY:
MATERIAL:
FINISH:
HEAT TREAT:
DATE: OF 1SHEET
UNLESS OTHERWISE SPECIFIED
AND TOLERANCES ARE
.005
ANGLES 1/2
FRACTIONS 1/32
DECIMALS 2 PL .02
DECIMALS 3 PL
UNLESS OTHERWISE SPECIFIED
REMOVE ALL BURRS
2
