Controls the driving direction of the truck
Anticlockwise rotation
turns the truck to the left; clockwise rotation
turns the truck to the right.
Caution
The forklift is equipped with a fully
hydraulic steering mechanism. When the
engine shuts down, it will be very difficult
to steer the forklift. Before turning again,
the engine must be restarted
immediately.
[Horn button 2]
The horn will sound by pressing the horn
button in the center of the steering wheel.
Combination light switch [3] (Indicator light
and light combination light switch)
The indicator light switch is on the right side of
the steering column and the switch is toggled
when turning.
Push forward-left turn indicator light; N-neutral;
pull back-right turn indicator light.
The indicator light switch does not return to
the neutral position automatically, and must be
reset manually.
To turn on the headlights and the front signal
light, turn this switch to align the position
marker on the switch handle with the
corresponding symbol on the switch body.
Ignition key switch [4]
O (off): The position to insert and pull out the
key; when the key is in this position, the engine
shuts down.
┃(On): When the start key is in “┃”, the circuit
is connected; after the engine is started, the
key remains in this position.
(Start): When the key is in the “ ”
position, the engine is started; after the engine
is started, the key automatically returns to the
“┃” position after release.
Diesel engine
When starting, the key is turned to the “ ┃ ”
position and the preheat indicator light turns
on for a while; after the light turns off, the key
can be rotated to the “ ” position to start
the engine.
Caution
1. When the engine stops, do not leave the
key in the “ ┃ ” position to avoid battery
discharge.
2. When the engine is running, do not put the
key in the “ ” position to avoid starter motor
damage.
3. When starting, the starter motor cannot
