HANGCHA CPCD15 - Page 50

44
the human body. If you swallow it by
accident, you should induce vomiting
immediately and go to hospital.
· Keep children away from the antifreeze.
6.Hydraulic oil tank level check
Check the fuel quantity in the hydraulic oil tank
1.5t-1.8t:
The scale line “L” marks the lower limit of the
hydraulic oil level, and the hydraulic oil level
must be higher than this scale line for trucks
with an mast no greater than 4 m.
The scale line “M” marks the lower limit of the
high mast, and the hydraulic oil level must be
higher than this scale line for trucks with mast
over 4 m and trucks equipped with
attachments.
The scale line “H” marks the upper limit of
hydraulic oil level, but it may be higher than
this limit for trucks equipped with attachments.
2.0t-3.5t square oil scale has scales on three
sides; the circled number on the top indicates
the applicable model tonnage (see the figure):
Symbol
○
25
scale value is applicable to 2t-2.5t
forklift trucks.
Symbol
○
30
scale value is applicable to 3t-3.5t
forklift trucks.
When the mast is in the minimum position, the
refuelling quantity is as follows:
2t-2.5t standard mast requires hydraulic oil to
be added to above scale “42” and the forklift
truck with tertiary mast requires hydraulic oil
to be added to above scale “45”;
3t-3.5t standard mast requires hydraulic oil to
be added to above scale “47” and the forklift
truck with tertiary mast requires hydraulic oil
to be added to above scale “50”;
In addition to meeting the aforesaid
requirements, the refuelling liquid level should
not exceed the scale mark by 30mm.
The full free lift mast, sideshift fork mast and
installed accessory mast should be
implemented according to the aforesaid
standards.
7. Brake fluid quantity check
