⑤ Split rear rim bolts.
11. Brake and inching pedal check
With the engine still running, press the brake
pedal fully down and the distance between the
surface of the brake pedal and the front floor
should be 60mm or more.
Check the height of the inching pedal in the
same way.
1.5t-3.5t height and free clearance:
12. Hand brake
Make sure the hand brake handle acts normally
after it is tightened and then loosened to its
original position.
Tension requirement: 147N-196N
