diagram and lock them temporarily.
j
）
Start the engine and remove the wooden
blocks from the forklift frame.
k
）
Tilt the forklift frame backward so that the
forklift is slowly lowered, and then take out the
wooden blocks under the forklift frame and at
the rear wheels.
l
）
Tighten the tire bolts symmetrically and
crosswise in sequence.
m
）
Adjust the tire pressure to the specified
value.
Rear tires
a）Park the forklift on level and solid ground.
b）Tighten the hand brake and place wooden
blocks behind the front wheels to prevent the
forklift from moving.
c）Place the jack at the bottom cutout of the
counterweight as shown in the diagram.
Note: Make sure the minimum bearing weight
of the jack is 2/3 of the total weight of the
forklift truck.
d ） Loosen the nuts on the wheel 1-2 turns
counterclockwise.
Warning
Do not remove the nuts until the rear
wheels are lifted off the ground.
e）Slowly lift the forklift with a jack until the
rear wheels are completely off the ground.
Place wooden blocks on each rear side of the
forklift frame to support the forklift as shown
in the diagram.
f）Remove the wheel nuts and replace the rear
tires.
Warning
When removing the tire from the hub,
the rim bolts and nuts should not be
removed until deflating.
Make sure that the wooden blocks used
