Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
35
8.4 Attached table 4
Ser
ial
No
Code
model
Diagram of special-
shaped support ring
remarks
1
03-03.7
Z10-15
Measure the external
cylindrical surface R10~R15
2
03-03.8
Z14.5-30
Measure the external
cylindrical surface R14.
5~R30
3
03-03.9
Z25-50
Measure the external
cylindrical surface R25~R50
4
03-03.10
HZ11-13
Measure the internal
cylindrical surface R11~R13
5
03-03.11
HZ12.5-17
Measure the internal
cylindrical surface
R12.5~R17
6
03-03.12
HZ16.5-30
Measure the internal
cylindrical surface
R16.5~R30
7
03-03.13
K10-15
Measure the external
spherical surface
SR10~SR15
8
03-03.14
K14.5-30
Measure the external
spherical surface
SR14.5~SR30
9
03-03.15
HK11-13
Measure the internal
spherical surface
SR11~SR13
10
03-03.16
HK12.5-17
Measure the internal
spherical surface
SR12.5~SR17
11
03-03.17
HK16.5-30
Measure the internal
spherical surface
SR16.5~SR30
12
03-03.18
UN
Measure the external
cylindrical surface, the
radius is adjustable R10~∞
