4 - System setup
53
14. Check the data in the overview.
Press to confirm selection.
μ
ATTENTION! If Offsets need to be corrected,
then press the button to change the
antenna settings for the Selected Vehicle in
the drop down menu, before confirming
selection.
15. Create Implement by pressing the
button.
16. Implement Information:
A. Press the “Make” to type in the
implement name.
B. Press the “Model” to type in
the implement model.
C. Press to confirm.
Operating Configuration Wizard: Vehicle
Select Vehicle
JD 4630
Offsets
Antenna Location from Rear Axle
Antenna Location from Centerline
Antenna Height from Ground
Rear Drawbar
Rear Lift Arms
Front Lift Arms
Operating Configuration Wizard: Implement
Select Implement
Implement Wizard: Make and Model
Make
Model
Enter Implement Information
