3 - Description
26
Spray Boom
Boom and Terminology
The sprayer is fitted with a VPZ boom. The boom is supported by a trapeze fitted to the tank frame.
The trapeze helps the boom to stay horizontal when unfolded, and it protects the boom against vibrations and shocks, when
driving on uneven ground. This ensures longer boom life and improves boom stability for better spray distribution.
Booms are available in 20, 21, 24, 27 and 28 m working width. All booms are provided with spring loaded breakaway.
For 3-folded booms, the terminology is as follows:
A - Centre section
C - Middle section
D - Outer section
E - Breakaway section
